Very Small Form Factor Multi-fiber Connector, MMC

Info - communications
Jump To:
OVERVIEW FEATURES APPLICATION WHY CHOOSE SUMITOMO ELECTRIC CONTACT US Related Information

Innovative Connector that Succeeds MPO and Extremely Reduces Foot Print

MMC connector enables deployment of next-generation, high-density, multi-fiber cabling solutions, by combining a novel, reduced footprint multi-fiber ferrule with a very small Form factor connector footprint which is 1/3 the size of the MPO format.

Compliant with US Conec design

WHY CHOOSE MMC

Icon-ultra-compact

Small Form Factor Connector Embodiment

Fiber-count

Leverage the Advantage of High Fiber Count Cables

Icon low loss_05030

Meet the Industry’s Low Loss Requirement

Precision Molding Technology to Produce Solutions Utilizing MMC

32MMC_vs_MT_520

Specially Designed Ferrule with 32 fibers

32MMC_vs_MT_520

  • 32 fibers are arranged in 2 rows

  • Proven standard 32-MT mechanical and fiber alignment structure

  • Supports ganged insertion applications

Achieves Low Loss in 32-channel Random Connections

32MMC_histogram_portrait

  • Typ. IL < 0.21 dB, Max. IL < 0.30 dB at λ = 1310nm

  • Typ. RL > 75 dB, Min. RL > 65 dB at λ = 1310nm

  • n=1344 channels ( 42 pairs )

32MMC_histogram_portrait

MMC Connector Enables Higher-density Fiber-optic Cabling Solutions that Cannot be Met with Existing MPO Technology

5418-Patch-full-1680-344

Realizes 3x Dense Fiber Patch Panel compared to MPO

  • 32-fiber MMC x 216 ports per 1U rack enables total 6912-fibers in 1U

  • Improves connector density with enabling ganged insertion

Small Form Factor On-board Optics Connectivity

  • Total of 128-fiber connections per transceiver are available

  • The smaller footprint housing available for on-board or behind panel walls mount

Realizes 3x Dense Fiber Patch Panel compared to MPO

  • 32-fiber MMC x 216 ports per 1U rack enables total 6912-fibers in 1U

  • Improves connector density with enabling ganged insertion

Small Form Factor On-board Optics Connectivity

  • Total of 128-fiber connections per transceiver are available

  • The smaller footprint housing available for on-board or behind panel walls mount

Sumitomo Electric Provides End-to-End Solutions

From materials to measurement, we have all capabilities in-house to offer the optimal interconnect solution.

MaterialDesignManufacturingMeasurement
